The EA-550-DAS Series Switchover is an automatic mechanical switchover system designed to supply high purity Carbon Dioxide or Nitrous Oxide continuously. This automatic switchover system features integral heaters within the line regulator. These heaters ensure a high flow of inert gases, especially those prone to freezing due to high flow rates. By applying heat directly to the regulator, we eliminate the possibility of dry ice particulates forming in the seat, which can interrupt gas supply—a common issue with separate heating devices.

The standard unit includes two 36” cryogenic stainless steel lines with checked CGA-320 fittings. We can also modify the switchover to include additional heaters or accommodate more gas cylinders, depending on your needs.

Typical applications for the EA-550-DAS Series include:

The post EA-550-DAS Dual Tank Auto Switchover appeared first on E-Z Systems Inc..

The post EP-LPA Low Pressure Alarm appeared first on E-Z Systems Inc..

The EA-6500 thermostatically-controlled CO₂ heater that prevents freeze-ups caused by high flow rates. Allows the use of up to four CO₂ cylinders simultaneously. Incorporates check valves in stainless steel jacketed hoses.

EA-6500 includes:

• 4 stainless steel pigtails with check valves

• 1000 watt heater to prevent freezing

•  Ultra-high flow regulator

Specifications:

• 0–200 psi Output

• Maximum inlet pressure 4500 psi

• 1000 watt/120VAC

• CGA 320 brass connectors

The post EA-6500 Multi Tank Heater Assembly (0–200 PSI Output) appeared first on E-Z Systems Inc..

Preset to distribute CO₂ within AVMA recommended range of 30 – 70% fill rate for industry standard mouse and rat cages. Heated Preset Regulator can safely deliver the new 30% – 70% flow rate for two separate outputs (mouse and rat). Heater prevents tank freeze up when delivering the new higher flow rates.

Connects directly to the CO₂ cylinder with CGA-320 fitting. (Optional CGA-940 Yoke fitting available. EP-2230 Hose Kit also available)

The post EP-2200H Heated Dual Preset Tank Regulator with Restrictors appeared first on E-Z Systems Inc..

 Tank Talker Monitor System Features:

• 7” touch screen
•  Easy setup
• Connects to wifi for email alert features
• Remotely access your tank levels
• Will adapt to existing regulators (regulator not included)
• 1/4” NPT thread
•  Monitors two gas sources simultaneously
• Works in conjunction with SMARTBOX Touch Screen controllers
• Fully adjustable alarm settings
• Email alerts notify user of the location and remaining pressure
• Visual & audio alarm displayed on 7” monitor

EA-350 includes:
Transducer and Monitor

The post EA-350 Tank Talker Wireless Tank Monitor System appeared first on E-Z Systems Inc..

 Tank Talker Monitor System Features:

•  Easy setup
• Connects to wifi for email alert features
• Remotely access your tank levels
• Will adapt to existing regulators (regulator not included)
• 1/4” NPT thread
•  Monitors two gas sources simultaneously
• Works in conjunction with SMARTBOX Touch Screen controllers
• Fully adjustable alarm settings
• Email alerts notify user of the location and remaining pressure
• Visual & audio alarm displayed on SMARTBOX Touch Screen

EA-300 includes:
Wireless Transmitter, Software

The post EA-300 Tank Talker Wireless Tank Monitor Option (Discontinued) appeared first on E-Z Systems Inc..

0 – 40 PSI Output

EA-255 Inline high flow regulator for use when gas cylinders are not present in room. Does not connect directly to CO₂ cylinders.

Regulator incorporated with heater assembly for use with M2-SBFF-P, MSVF-4, and MSVF-8 Systems.

The post EA-255 Solo Gauge Inline Regulator (0–40 PSI Output) appeared first on E-Z Systems Inc..

The fully-automatic EZ-538 Series IntelliSwitch II™ gas switchover is a revolutionary new
generation of gas management systems.

The IntelliSwitch II features proprietary onboard I-Link web server technology that allows remote monitoring, secure system configuration, and e-mail notification of real-time system status and events. Ideal for interchangeable service/continuous supply in analytical laboratory, chemical process, instrumentation, and critical gas supply applications.

The IntelliSwitch II offers continuous gas pressure and flow control from liquid or high pressure cylinder sources. The end-user selects the mode of supply by the simple push of a button. Proprietary software logic lowers yearly gas costs by eliminating liquid cylinder vent loss and excess residual return.

The post EZ-538 IntelliSwitch II appeared first on E-Z Systems Inc..

25 – 125 CFH (12-60LPM) Output

Connects directly to CO₂ cylinder. Incorporated thermostatically controlled heater prevents regulator from freezing during high flow rates.

Includes: 9 foot connection hose with quick disconnect fitting.

The post EA-285 Heated Regulator (25-125 CFH Output) appeared first on E-Z Systems Inc..

0 – 100 PSI Output

EA-550 Connects directly to the CO₂ cylinder with CGA-320 fitting.  Capable of handling high flow rates. Incorporated electric heater keeps unit from freezing during operation. Standard 120 VAC

Includes: 9 foot connection hose with quick disconnect fitting.

The post EA-550 Heated PSI Regulator (0–100 PSI Output) appeared first on E-Z Systems Inc..
